ZYR
●
●
●
●
ZYR
9'84" to 18'04"
Overall Length
5'91"
Overall Width
116.84 to 163.14 lbs
Net Weight
3 to 12
Maximum People
/
Fuel Tank
/
Max HP / KW
INTRODUCE
An inflatable boat with a free bottom board, which can be freely assembled and provides strong stability.
Choose your size in this range：
• ZYR-300 / 9'84"
• ZYR-380 / 12'47"
• ZYR-430 / 14'11"
• ZYR-550 / 18'04"
Optional range of baseplates：
• Aluminum alloy bottom
• Inflatable bottom
• SLAT bottom
Engine:
Outboard，1 engine
Deck:
Open Deck，Removable chair board
Sailing Program:
Yacht tenders，Fishing boat
Materials:
PVC or Hypalon，Aluminum
People Capacity:
3 to 12 Persons
Size:
300CM to 550CM / 9'84" to 18'04"
STANDARD PACKAGE
• Oars
• Double action pump
• Portable bag
• Repair kit
• 1 Wooden chair board(Below 300CM / 9'84" )
• 2 Wooden chair board (Above 320CM / 10'5")
OPTIONAL
• Electric inflation pump
• Aluminum alloy chair board
• PVC anchor base
• Aluminum alloy anchor base
• Bow bag
• Seat bag
Brand:
Design Category:
C
Detail Display
SPECIFICATIONS
- Imperial
- Metric
-
- Commodity name: ZYR
- 设计类别: C
- 总长: 9'84" to 18'04"
- 总宽: 5'91"
- 重量: 116.84 to 163.14 lbs
- 马力: /
- 油箱: /
- 最大载人数: 3 to 12
ZYR
ZYR-300
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
9'84"
9'84"
5'91"
2'95"
1'48"
Maximum People
Net Weight
Maximum Load
Air chambers
3
114.64lbs
1073.65lbs
4 + 1 + 2
ZYR-380
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
12'47"
9'51"
5'91"
2'95"
1'48"
Maximum People
Net Weight
Maximum Load
Air chambers
6
127.87lbs
1739.45lbs
4 + 1 + 2
ZYR-430
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
14'11"
10'83"
5'91"
3'28"
1'64"
Maximum People
Net Weight
Maximum Load
Air chambers
9
149.91lbs
2396.42lbs
4 + 1 + 3
ZYR-550
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
18'04"
14'76"
5'91"
3'28"
1'64"
Maximum People
Net Weight
Maximum Load
Air chambers
12
163.14lbs
3020.33lbs
4 + 1 + 4
-
ZYR-300
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
300CM
210CM
180CM
90CM
45CM
Maximum People
Net Weight
Maximum Load
Air chambers
3
52KG
487KG
4 + 1 + 2
ZYR-380
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
380CM
290CM
180CM
90CM
45CM
Maximum People
Net Weight
Maximum Load
Air chambers
6
58KG
789KG
4 + 1 + 2
ZYR-430
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
430CM
330CM
180CM
100CM
50CM
Maximum People
Net Weight
Maximum Load
Air chambers
9
68KG
1087KG
4 + 1 + 3
ZYR-550
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
550CM
450CM
180CM
100CM
50CM
Maximum People
Net Weight
Maximum Load
Air chambers
12
74KG
1370KG
4 + 1 + 4
