ZY-500BM
●
●
●
●
●
ZY-500BM
16'4.9"
Overall Length
5'
Overall Width
93.7lbs
Net Weight
4
Maximum People
/
Fuel Tank
/
Max HP / KW
INTRODUCE
Suitable for rescue on ice, marsh, mudflat and water.
Features：
Double sided hollow design, the hull can pass over the head of the trapped person during rescue, and rescue personnel do not need to leave the center position of the rescue ship, and can directly carry out drag rescue.
CONFIGURATION
STANDARD PACKAGE:
• Emergency oars
• Stretchable rescue hook
• Double action pump
• Repair kit
• Portable bag
Brand:
Design Category:
C
Detail Display
SPECIFICATIONS
- Imperial
- Metric
-
- Commodity name: ZY-500BM
- 设计类别: C
- 总长: 16'4.9"
- 总宽: 5'
- 重量: 93.7lbs
- 马力: /
- 油箱: /
- 最大载人数: 4
- 救援艇概要: Multi functional rescue raft
ZY-500BM
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
16'4.9"
14'
5'
2'7.5"
1'1.4"
Air chambers
Boat only Weight
Maximum Load
Maximum People
4 + 1
93.7lbs
1102bls
4
-
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
500cm
428cm
152cm
80cm
36cm
Air chambers
Boat only Weight
Maximum Load
Maximum People
4 + 1
42.5KG
500kg
4
