ZYA-400JLII
●
●
●
●
●
●
●
ZYA-400JLII
13'12"
Overall Length
6'23"
Overall Width
216.05lbs
Net Weight
8
Maximum People
/
Fuel Tank
30HP /22.37KW
Max HP / KW
INTRODUCE
Suitable for various water environments, such as shorelines, rapids, inland rivers, urban waterlogging, transportation liaison, emergency training, transportation of disaster stricken people or materials, emergency rescue training, and other tasks.
Features：
The device with a rear arch shape can prevent overturning and protect the engine from water ingress. The ship has a shallow draft at the bottom, light weight, flexibility, a pointed bow, a V-shaped front and flat rear of the bottom, and good wave breaking performance. Double nozzles make the ship more stable and resistant to capsizing. The aluminum magnesium alloy tailboard can withstand greater thrust from the engine and is equipped with a high-low tailboard converter. The high and low tailboards can be used freely, with lifting rings and external engine fixing rings for lifting and fixing the external engine. The bottom plate has foot fixing devices to prevent personnel from being easily thrown out of the ship.
CONFIGURATION
STANDARD PACKAGE:
• Emergency oars
• Stretchable rescue hook
• Double action pump
• Boarding ladder
• Repair kit
• Foldable and inflatable stool
• Inflatable stool
• Portable bag
• Inflatable salvage bar
OPTIONAL:
• Electric inflation pump
• High and low stern board switching device
Brand:
Design Category:
C
Detail Display
SPECIFICATIONS
- Imperial
- Metric
-
- Commodity name: ZYA-400JLII
- 设计类别: C
- 总长: 13'12"
- 总宽: 6'23"
- 重量: 216.05lbs
- 马力: 30HP /22.37KW
- 油箱: /
- 最大载人数: 8
- 救援艇概要: Easily-righting rapids rescue boat
ZYA-400JLYF
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
13'12"
8'73"
6'23"
2'95"
1'64"
Air chambers
Boat only Weight
Maximum Load
Max HP / KW
Maximum People
4 + 4
216.05lbs
2381bls
30HP / 22.37KW
8
-
Overall Length
Internal Length
Overall Width
Internal Width
Tube Diameter
400cm
266cm
190cm
90cm
50cm
Air chambers
Boat only Weight
Maximum Load
Max HP / KW
Maximum People
4 + 4
98KG
1080KG
30HP / 22.37KW
8
